PE foam protective profile "U 80-100" 1m
PE foam protective profile "U 80-100" 1m
Previous
Next
PE foam protective profile "U 80-100" 1m
PE foam protective profile "U 80-100" 1m
(0)

PE foam protective profile "U 80-100" 1m

|
POU-80-100
64.05 € tax incl.
53.55 € tax excl.
1.82 € gross/pcs.
1.53 € net/pcs.

The minimum purchase order quantity for the product is 35.

BoxmarketPro Sit back in the chair, relax, and let the professionals work! Soon you will receive the best offer provided by your individual caretaker.

Icon - Shipping up to 7 working days
Shipping up to 7 working days
Icon - Return to 30 days
Return to 30 days
Quantity Price tax incl./tax excl.
> 1 szt. 1.82 € 1.53 €
> 70 szt. 1.73 € 1.45 €
> 105 szt. 1.67 € 1.41 €
Colour
Blue
Material
Polyethylene (PE)
Length (mm)
1000.00
EAN
5905489976202

PE foam "U 80-100" protective profile 1 m - Extremely wide shield for stone blocks, Jumbo XXL glass, and industrial panels 🛡️

"U 80-100" is the record wide foam profile by Boxmarket. It safely covers the edges of elements with a thickness of 80 - 100 mm: 90 mm granite countertops, massive stair steps, Jumbo quartz sinter plates, 100 mm facade panes, and powerful composite panels for wagons and elevators. Despite its huge throat, a 1,000 mm section weighs only ≈ 35 g, so it does not wind up freight costs. Closed-cell PE foam acts like a network of micro air cushions, absorbs shocks, and eliminates edge chipping. The characteristic blue color facilitates quality control from production to assembly on site.


What is a PE foam protective profile?

"U" shaped profile is created through the continuous extrusion of foamed polyethylene (EPE/LDPE). The widest "U 80-100" throat automatically encompasses edges of 80 – 100 mm and provides three key functions:

  1. Cushioning: millions of closed cells disperse impact energy, protecting stone, glass, and composites from chipping.
  2. Separation: the resilient spacer maintains an equal gap between panels, eliminating friction scratches.
  3. Auto-grip: extremely wide arms embrace the edge without tape - the installation lasts <1 s.

Material – foamed polyethylene LDPE/EPE

  • Density 30 kg/m³: high elasticity, resistance to crushing up to 60% - no crumbling at -40 °C.
  • Hydrophobic: closed-cell structure without micropores - does not absorb water, does not mold, and does not gain weight.
  • Chemical inertness: LDPE does not react with paints, oils, or metals; does not discolor surfaces.
  • Ecology: free from CFC/HCFC, 100% recyclable in the LDPE #4 stream.

🛡️ Profile properties – cushioning & auto-grip

  • 🤲 "Click & slide" assembly: the profile instantly clamps onto the edge of 80 – 100 mm.
  • 🌡️ Range from -40 °C ... +90 °C: it doesn't crumble or soften.
  • 🔄 > 10 re-use cycles: 50% compression tests without permanent deformation.
  • 🛠️ On-site cutting: a utility knife or foam guillotine are enough to get any length.

🚚 Applications in packaging and logistics

  • 90 mm granite blocks: edge protection during crane lifting.
  • 100 mm facade glass: damping micro vibrations in the transport of glass modules.
  • Composite wagon / window plates: panel spacing, powder coating protection.
  • XXL stone stairs: safe distance in A-frame racks.
  • 80 mm fire door wings: the profile protects frames and veneers from bumps.

🏭 Industries using the U 80-100 mm profile

  • Stonemasonry 🪨 – countertops and steps > 80 mm.
  • Façade construction 🏗️ – structural glass modules.
  • Luxury furniture 🛋️ – bars and tables with massive edges.
  • Aerospace & rail ✈️🚆 – thick composite panels.
  • Heavy-duty logistics 📦 – shipping of XXL "flat-pack" sheets.

⚖️ Solid cardboard vs PE Foam – key differences

The table below compares LDPE foam profiles and solid cardboard corners:

Aspect Foam profile (LDPE) Cardboard corner
Material / production Foamed LDPE, continuous extrusion; petrochemical raw material. Layered KRAFT paper, "V" profile; renewable raw material.
Protective properties Soft cushioning, dampens vibrations; no structural load capacity. Rigid arm, transfers pressure; less cushioning.
Weight / volume ≈ 35 g/pc.; arms ≈ 24 mm → larger package dimensions. ≈ 210 g/pc.; 3 mm wall → minimal volume increase.
Resistance to moisture / chemicals Hydrophobic, chemically neutral. Hygroscopic; PE coating – waterproof.
Recycling / ecology Recycling LDPE #4; no biodegradation. Biodegradation or waste paper; low carbon footprint.
Palletization / stacking Does not carry weight – only cushioning. Carries loads; allows stacking.

Looking for cardboard corners? Check out our full offer ➜


💰 Logistic and economic benefits

  • 💸 Price < 3.80 PLN/pc. per pallet (30 pcs./carton) – cost is recovered after one avoided complaint of a stone slab.
  • ⚖️ Margin weight: < 0.06% of the weight of a 60 kg stone block.
  • ⏱️ Shortened packing time −30% vs wrapping in foil and cardboard.
  • 🔄 > 10 re-use cycles in a closed return circuit.
  • 📉 Complaints −35% (facade manufacturers' data, 2025).

⚙️ Technical specification

  • Model / Name: U Profile 80-100 mm, length 1 000 mm
  • Material: foamed polyethylene (EPE LDPE)
  • Edge thickness range: 80 – 100 mm
  • Segment length: 1 000 mm
  • Foam density: 30 kg/m³
  • Color: blue
  • Weight: ≈ 35 g/pc.
  • Product code: POU-80-100 / EAN 5905489976202

🛠️ Custom product configurators – match the filling to your process

Fill the "U 80-100" profiles with PE foam sheets and cardboard dividers, creating a complete protection system:

🔹 Custom PE foam sheets

The creator foam sheets - enter dimensions (10 - 50 mm) and color to immediately know the price.

🔸 Custom cardboard dividers

The creator cardboard dividers allows you to determine the format, number of layers and grammage.

🚀 How to build a coherent system?

  1. Reinforce the edges with U 80-100 profiles.
  2. Separate layers with PE foam sheets.
  3. Distribute pressure with cardboard dividers.
  4. Order everything in one basket - configurators will give the price and we will synchronize the production.

💡 Why is it worth it?

  • Instant price - immediate online valuation.
  • 🎯 Zero material loss - each component is custom.
  • 📉 Less logistics damage thanks to the tailored system.
  • 🛒 One invoice - profiles, sheets and dividers together.
  • 🚚 Shortened lead time - parallel production of all elements.

📞 Wholesale orders and advice

Packing massive stone slabs, Jumbo glass or panels up to 100 mm thick? Contact the Boxmarket team - we will prepare an offer for U 80-100 profiles and adjust PE sheets and cardboard dividers so that your supply chain is fast, safe and economical.
